L-shaped steel profiles

产品 #

The 10 mm steel L-shaped profiles from fuma-Bautec have been specially developed to protect tile edges. They are suitable for all domestic and commercial areas with a length of 250 m.

颜色/表面处理:

产品概述

L-shaped profiles by fuma-Bautec were especially developed for protection of tile edges. They are suitable for all domestic and commercial areas. Because of their special angle and different materials, it is possible to provide edge protection even in areas of permanent and strong stresses. These special profiles were designed to transfer impact stresses uniformly into the tile covering and base material. This minimises the chances of damage to the decorative covering. Besides the protective function, the L-shaped pro- files also meet the highest decorative requirements. They provide clean transitions and limits, e.g. between carpet and parquet. They can be used as edge protection as well as for surface definition.

信息和指南

  • 产品规格书
  • 保证
  • 营销信息
  • 安全数据表
  • 批准和认证
  • 安装信息

特点和优势

  • Height: 10 mm
  • Length: 250 cm
  • Material: V2A stainless steel (304) Material number: 1.4301 Ingot X5CrNi18-10
  • Fire resistance according to DIN EN 13501: A1 (non-flammable)
  • Linear expansion coefficient: 16 x 10-6 m/m°C
  • Approx. density: 7.9 kg/dm3
  • Approx. hardness: 250 HB
  • Tensile strength Rm at 20 °C: 500 – 700 N/mm2
  • Elongation A5 at 20 °C1 %: 35%
  • Yield strength Rp 1.0 at 20 °C: 250 N/mm2
  • Other properties: Production control according to DIN 18200

产品说明书

产品编号
专利号
可用颜色 Polished Stainless Steel (Gloss)
系统组分
在以下国家/地区有售 Costa Rica, Honduras, Panama
适用基面
包装尺寸

可用保修

WARRANTIE (English)
